Feed type | Pneumatic |
Press stroke | 40 or 30 mm |
Cross section range | 0.08 – 6 mm ² (28 – 9 AWG) |
Crimp height adjustment (wire & insulation) | Increment: 0.025 mm Max.: 2.0 mm |
Terminal pitch range | Max.: 40 mm |
Terminal thickness | < 1.2mm |
Weight | 5.0kg |
Feed System | Side Feed & Rear Feed |
